Hydraulic Pump
Hydraulic Pump
PVV5 hydraulic vane pump Rexroth Replacement
557d41b1-80e2-4cce-a522-a58b7599f42e
0ae7ff96-ebee-47ed-b708-77193bec2d07
74af785c-fd7c-4333-b55e-5e53014d3eb5
1b424cd5-22e8-4c61-8ac2-83d4eb325ba9

PVV Series Fixed Displacement Vane Pumps

Size 4 5 8 11 14 16 19 22 25 28
Series       Series 1x               Series 2x
Displacement
geometric, per revolution		   Vg cm³ 4 55 8 11 14 16 19 225 25 28
Pressure at suction port S 1) absolute pe bar 0,7 ... 3               0,7 ... 3
Maximum continuous pressure   p1 bar 250 250 250 250 250 250 210 180 195 170
Maximum intermittent pressure 2)   p2 bar 280 280 280 280 280 280 230 210 225 200
Maximum pressure peaks   p3 bar 300 300 300 300 300 300 250 230 265 240

                                        ν = 12 mm²/s
Minimum speed at

                                        ν = 25 mm²/s		 p < 100 bar nmin rpm 600 500 500 500 500 500 500 500 500 500
p = 100 bar … 180 bar nmin rpm 1200 1200 1000 1000 800 800 800 800 800
1000		 800
1000
p = 180 bar … p2 nmin rpm 1400 1400 1400 1200 1000 1000 1000 1000
at p2 nmin rpm 700 700 700 600 500 500 500 500 500 500
Maximum speed at p2 nmax rpm 4000 4000 4000 3500 3000 3000 3000 2500 3000 3000
  Machine Hydraulci Pump/Motor
Construction Machinery
Concrete mixer AA2FM A4VTG EATON 5423
Concrete transport pump A2FO A4VG A11V
Wet spraying machine A11V A2FM A10V
Road roller A6VE A6VM  A4VTG P2VC
Paver A6VE A6VM  P2VC P4VC
Grader A6VM  P2VC
Asphalt spreader P1V(A)O A2FM
Milling machine P1V(A)O A2FE A2FM
Crawler excavator P3VO
Wheel excavator A6V A6VM  P3VO
Loader M3VE A6VM  P2VC A10VSO A2FM
Bulldozer A6VM  P2VC
Material Handling Machinery
Crane A2FE A6V A6VM P2VC P1V(A)O A10VSO A2FM
Forklift
Drilling Rig A2FE A6VE A6VM P1V(A)O A10VSO A2FM
Heading Machine A2FE P1V(A)O
Mining Truck A10VSO
Agricultural Machinery
Tractor A6VE P2VC P4VC A10VSO
 Rice Transplanter
Combine Harvester A6VE A4VTG P2VC
Pesticide machine A6VE A4VTG P2VC A10VSO
Rice harvester A6VE A4VTG P2VC P4VC
Sugar Cane Harvester A6VE P2VC P4VC A10VSO A2FM
Municipal Machinery
Airport Equipment A6VM P2VC P1V(A)C A10VSO A2FE A2FM
Firfighting Truck A7VO P1V(A)C A10VSO
Snow Sweeper P2VC A10VSO
Aerial work platform P4VC A10VSO
Electric Power A2FE A6VE P2VC P4VC
Environmental Sanitation Vehicle
Anti Dust Vehicle
Oil And Gas Equipment
Liquid Nitrogen Pump Truck P1V(A)O
Fracturing Truck A6VM P2VC A2FO A2FM
Fracturing Blender Truck A6VM P2VC A10VSO A2FM
Coil Tubing A10VSO A2FE
Pipelayer A2FE A6VM P1V(A)O
Industrial Application
Injection molding machine
Shoe-making machine A10VSO
Metal forming machinery A7V
CNC machine tool PV A10VSO
Metallurgy and die-casting E-A4VG
Flow Machine
Reach Stacker P3VO
Heavy Forlift A6VM A4VTG A10VSO
Tire Crane A6VM
Maritime Port
Ship A6VE A6VM P1V(A)O A10VSO A2FE A2FM
Offshore platform A6VE A6VM P1V(A)O A10VSO A2FE A2FM
Wind power P1V(A)O
Dredging vessels P1V(A)O
Others
Marine Crane A 11VLO A2FM FMF  A4VG A6VM
